APC Smart-UPS C 1500VA 2U LCD

• Maximises battery performance, life, and reliability through intelligent, precision charging
• Protects connected loads from surges, spikes, lightning, and other power disturbances
• Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
• Maximises useful battery life by widening the input voltage window or tightening the output
• voltage regulation
• Provides remote power management of the UPS over the network


Output

• Output power capacity
  1.0 KWatts / 1.5 kVA
• Max Configurable Power (Watts)
  1.0 KWatts / 1.5 kVA
• Nominal Output Voltage
  230V
• Output Voltage Note
  Configurable for 220 : 230 or 240 nominal output voltage
• Output Voltage Distortion
  Less than 5% at full load
• Output Frequency (sync to mains)
  47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
• Other Output Voltages
  220, 240
• Topology
  Line Interactive
• Waveform type
  Sine wave
• Output Connections
  (8) IEC 320 C13 (Battery Backup)

Input

• Nominal Input Voltage
  230V
• Input frequency
  50/60 Hz +/- 3 Hz (auto sensing)
• Input Connections
  IEC-320 C14
• Cord Length
  1.83 meters
• Input voltage range for main operations
  160 - 286 V
• Input voltage adjustable range for mains operation
  151 - 302 V
• Number of Power Cords
  1
• Other Input Voltages
  220, 240

Batteries & Runtime

• Battery type
  Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
• Typical recharge time
  3 hour(s)
• Replacement Battery
  RBC7
• RBC Quantity
  1
• Battery Volt-Amp-Hour Capacity
  408
• Runtime
  View Runtime Graph
  View Runtime Chart
• Efficiency
  View Efficiency Graph

Communications & Management

• Interface Port(s)
  SmartSlot , USB
• Control panel
  Multi-function LCD status and control console
• Audible Alarm
  Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
• Emergency Power Off (EPO)
  --
• Available SmartSlot™ Interface Quantity
  1

Surge Protection and Filtering

• Surge energy rating
  459 Joules
• Filtering
  Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449

Physical

• Maximum Height
  219 , 21.9 cm
• Maximum Width
  171 , 17.1 cm
• Maximum Depth
  439 , 43.9 cm
• Net Weight
  24.09 kg
• Shipping weight
  27.23 kg
• Shipping Height
  376 , 37.6 cm
• Shipping Width
  328 , 32.8 cm
• Shipping Depth
  595 , 59.5 cm
• Color
  Black
• Units per Pallet
  12.0

Environmental

• Operating Environment
  0 - 40 °C
• Operating Relative Humidity
  0 - 95 %
• Operating Elevation
  0-3000 meters
• Storage Temperature
  -15 - 45 °C
